Long Span Warehouse Mezzanine Systems , Temporary Storage Hi Level Mezzanine Floors

Model Number : T-steel mezzanine ZJ04

Certification : AS4084

MOQ : 50m²

Price : Negotiation

Payment Terms : T/T, L/C

Supply Ability : 10000m²

Delivery Time : 15-30 Days

Packaging Details : bubble foam

Material : Steel Q235/Q345, Steel Q235/245

Item : pallet rack mezzanine systems

Structure : Assembled

Weight Capacity : maximum 1000kg/m²

Color : Orange,Blue,Black,Gray

Length Span : 3000-6000mm/upright

Width Span : Max 6000mm/upright

Contact Now

Custom-made Long Span Steel Warehouse Storage Industrial Mezzanine Floors

Description:

A steel structure mezzanine floor or entresol is a raised platform that is independent of a building structure and is supported by steel columns.

Mezzanine floor can create additional floors of space for a variety of different uses such including storage or extra office space. Mezzanine floors are a very quick and cost effective way to create new space without the expense and inconvenience of relocation.

A steel structual mezzanine floor utilises the overhead space in your existing premises with the minimum of disruption and in most cases without the need for planning permission.

It is fully customised to a organisation’s own specific needs, available in a wide range of floor surfaces and sizes to maximize and improve space in order to get the best use from the total volume of the premises. A mezzanine floor can cope with many different applications, from light storage to the support of heavy machinery.

Mezzanine Floor Drawing-Model2.pdf

Mezzanine Floor Plan.pdf

Product Name Custom-made Long Span Steel Warehouse Storage Industrial Mezzanine Floors
Product No. ZJ
Max.loading capacity 200-1000 kgs/square meter
Upright section: 250*250*10mm 350*300*10mm 300*450*10mm
"H"post: 160*88mm 200*100mm 250*125mm 300*150mm 350*175mm
"H"Beams : 180*160mm 230*160mm 280*160mm 330*160mm
Color Customized
Material High-quality steel,Q235
Application warehouse
Finish Powder coated
Feature Corrosion protection
MOQ 1pcs
Payment Terms T/T ; L/C;Paypal
Delivery Time Shipped in 20 days after payment
Packing Details Packed in foam
Certification SGS ISO9001 AS4084:2012
OEM&ODM Support

Characteristic

1.Can enhance the shelf height attic shelves full use of warehouse height, better use of storage space.
2.Attic shelves shelf dedicated floor laying steel gusset plate, load capacity, good integrity, carrying layer uniformity, smooth surface, easy to lock and other characteristics.
3.Attic shelves full account of user-friendly logistics, design aesthetics, structure and generous, assembly installation and removal easy, according to the ground, flexible design.
4.According to various floor design custom installation, can be easily assembled on site, without welding. Attic shelves for storing various types of items.
5.Optional downstairs forklifts, hydraulic lifts, freight elevators, etc. cargo, cargo transport is using a small trolley complete.

Long Span Warehouse Mezzanine Systems , Temporary Storage Hi Level Mezzanine Floors


Long Span Warehouse Mezzanine Systems , Temporary Storage Hi Level Mezzanine Floors

Shipping:

Long Span Warehouse Mezzanine Systems , Temporary Storage Hi Level Mezzanine Floors
