Heavy Duty Cold Roll Steel Moving File Cabinets Shelf System With Floor Tracks

Model Number : W-MFC2017526

Certification : ISO9001/14001

MOQ : 2-10 SETS

Price : Negotiation

Payment Terms : T/T, L/C, Western Union

Supply Ability : 100 SETS

Delivery Time : 15-30 Days

Packaging Details : Professional & Saft packaging for oversea shipment

Type : rolling lateral file cabinet Furniture

Material : Metal

Specific Use : Filing Cabinet

Usage : Library,school,office,bank

Feature : Corrosion Protection

Raw material : High Qulity Cold Roll Steel

Warranty : 3 years on normal use

Structure : Knock down

Contact Now

China Manufacturer Heavy duty Cold Roll Steel File Shelving Compact Mobile File Cabinet

Specification:

Shelf body	Stand Column	Cold-roll steel	1.5mm	GB708
	Partition Whole body partition partition flange 25mm (reinforcing rib under the partition)	Cold-roll steel	1.0mm	GB708
	Side plate	Cold-roll steel	1.0mm	GB708
	Upper cover plate (whole body side plate dimension 300X100mm)	Cold-roll steel	1.0mm	GB708
	Panel	Cold-roll steel	1.0mm	GB708
chassis	Main beam and whole frame board (every wheelo frame board have six : 55mm beam bush hole. every hole have sealing	Hot rolled steel plate	3.0mm	GB710
pathway	Rail	High quality steel plate	Solid square tube	GB710
	Rail box	High quality steel plate	26X95mm Thickness 3.0	GB710
	Pathway	High quality steel plate	50X185 Thickness 3.0	GB710
Transmission part	Handle crank	ZG45	Bothway overload clutch double axis transmission	GB1285
	Transmission shaft	Solid core 45 steel	Φ20	GB699
	Linkage rail	Seamless steel tube	Φ20X2.5	GB699
	Bearing	Precision bearing	HR6204	GB/T 307.3-2005
	Chain wheel	ZG45		GB1135
	Chain	FR420	Φ8.5, pitch12.7 breaking force 1800kg	GB1244
	Idler wheel	HT20-40	Cast iron	Gb11351
	Sealing rubber strip	Magnetic fluid sealant
	Dust shield	Cold-roll steel	1.0	Gb710
	Barb	Hot rolled steel plate	3.0mm	Gb711

Features

. Widely used in archives, library, government, bank and company documents center
. Instruction in package enables your installing very easy and fast
. Consists of fixed shelves installed on mobile chassis at bottom
. Every rack own transmission equipment
. Being compact can utilize room adequately and fully enclosed
. Only one aisle to be used, highest space utilization, nice and practical
. Sealing better, and can be manually and automatically operated
. Neat/elegant for file storage

Description:

Compact Mobile Filing Cabinet is a cost effective way of increasing storage capacity and utilizing valuable floor space, which can double storage capacity compared to conventional static shelving.
It is widely used in offices for file storage and are designed to be easily re-located with no floor fixing. It moves along floor tracks allowing the aisle to be moved so that the required shelves can be accessed, so only one aisle is needed.
Our Services
. Factory price with high quality
. OEM /ODM are available.
. Fast delivery.
. ISO,CE certified, one stop solution service for your project.
. Perfect design Exquisite technology, strict management, sincere service.
